Product Details:
|
| Place Of Origin: | Shandong,China | Grade: | Q235 |
|---|---|---|---|
| Shape: | C Shape Beam Steel | Standard: | GB |
| Dimensions: | 120*53*5.5 | Length: | Customer's Required |
| Technique: | Cold Bend | Sample: | Available |
| Packages: | Packing Standard | Tolerance: | ±1% |
| High Light: | 5.5mm Q235 C Shaped Steel Beam,Blasting C Shaped Steel Beam,5.5mm C Channel Beam |
||
Channel Steel Beam 12# 5.5mm Q235 C Shape Beam Steel
Product description
Channel steel is a long strip of steel with a groove section. It is a carbon structural steel for construction and mechanical use. It is a section steel with a complex cross-section, and its section shape is a groove shape.
Product details
Product parameter
| Grade | Q235 |
| Length | Customer's Required |
| Standard | GB,AISI,ASTM etc. |
| Technique | Cold bend |
| Surface Treatment | Clean, blasting and painting according to customer requirement |
| Thickness tolerance | ±0.1mm |
| Application | Channel steel is mainly used in building structure, curtain wall engineering, mechanical equipment and vehicle manufacturing. |
| MOQ | 5tons. |
| Shipment time | Within 5-8 workdays after receiving deposit |
| Capacity |
50000 tons/month
|
| Size | 120*53*5.5mm |
Theoretical weight reference
|
Specifications
|
Height
(mm)
|
Leg width
(mm)
|
Waist thickness
(mm)
|
Cross-sectional area
(cm²)
|
Theoretical weight
(kg)
|
|
5#
|
50
|
37
|
4.5
|
6.928
|
5.438
|
|
6.3#
|
63
|
40
|
4.8
|
8.451
|
6.634
|
|
6.5#
|
65
|
40
|
4.3
|
6.709
|
|
|
8#
|
80
|
43
|
5.0
|
10.248
|
8.045
|
|
10#
|
100
|
48
|
5.3
|
12.748
|
10.007
|
|
12#
|
120
|
53
|
5.5
|
12.059
|
|
|
12.6
|
126
|
53
|
5.5
|
15.692
|
12.319
|
|
14#a
|
140
|
58
|
6.0
|
18.516
|
14.535
|
|
14#b
|
140
|
60
|
8
|
21.316
|
16.733
|
|
16#a
|
160
|
63
|
6.5
|
21.962
|
17.24
|
|
16#b
|
160
|
65
|
8.5
|
25.162
|
19.752
|
|
18#a
|
180
|
68
|
7
|
25.699
|
20.174
|
|
18#b
|
180
|
70
|
9
|
29.299
|
23
|
|
20#a
|
200
|
73
|
7
|
28.837
|
22.637
|
|
20#b
|
200
|
75
|
9
|
32.837
|
25.777
|
|
22#a
|
220
|
77
|
7
|
31.846
|
24.999
|
|
22#b
|
220
|
79
|
9
|
36.246
|
28.453
|
|
25#a
|
250
|
78
|
7
|
34.917
|
27.41
|
|
25#b
|
250
|
80
|
9
|
39.917
|
31.335
|
|
25#c
|
250
|
82
|
11
|
44.917
|
35.26
|
|
28#a
|
280
|
82
|
7.5
|
40.034
|
31.427
|
|
28#b
|
280
|
84
|
9.5
|
45.634
|
35.832
|
|
28#c
|
280
|
86
|
11.5
|
51.234
|
40.219
|
|
30#a
|
300
|
85
|
7.5
|
34.463
|
|
|
30#b
|
300
|
87
|
9.5
|
39.173
|
|
|
30#c
|
300
|
89
|
11.5
|
43.883
|
|
|
32#a
|
320
|
88
|
8
|
48.513
|
38.083
|
|
32#b
|
320
|
90
|
10
|
54.913
|
43.107
|
|
32#c
|
320
|
92
|
12
|
61.313
|
48.131
|
|
36#a
|
360
|
96
|
9
|
60.910
|
47.814
|
|
36#b
|
360
|
98
|
11
|
68.110
|
53.466
|
|
36#c
|
360
|
100
|
13
|
75.310
|
59.118
|
|
40#a
|
400
|
100
|
10.5
|
75.068
|
58.928
|
|
40#b
|
400
|
102
|
12.5
|
83.068
|
65.208
|
|
40#c
|
400
|
104
|
14.5
|
91.068
|
71.488
|
Application
Channel Steel Beam is a long strip of steel with a groove section. It is a carbon structural steel for construction and mechanical use. It is a section steel with a complex cross-section, and its section shape is a groove shape.
FAQ
Q1:What is your terms of payment?
A: 30% T/T in advance, the balance 70% before delivery.
Q2: What is the terms of trade?
A: EXW, FOB, CIF, CFR, DDU.
Q3: What is the terms of packing?
A: Generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers'
requirement.
Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after received your deposit. For productiong period, it
usually takes about 15-30 days afer receiving the deposit.
Q5: Could you produce according to the samples?
A: Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.
